| 5gallon Drinking water production line: |
|
| Today, drinking water is more and more important for human life. Clean, Pure, Sanitation, Health is most important for drinking water. |
| |
| As a earliest developer, manufacturer of water treatment equipment, |
| |
| We always do our best for people in Drinking water. There are 3 tenets of our company: “Enterprising” “Innovation” “Perfect” |
|
| |
| |
| 120-200Barrel/H 5Gallon filling machinery |
| |
|
| |
| Automatic pull lid machine |
 |
Overall dimension：500*500*1750 Material：304 Stainless steel |
|
Pulling head：1 |
|
Air consumption：0.05m3/Min |
|
Production capacity：200 barrel/H |
|
Run route switch：1piece SHANGHAI |
|
Frame structure：38*38*1.2 Stainless steel |
|
Sealing board：1.0thickness，304 Stainless steel |
|
Pneumatic element：AIRTAC |
|
Voltage：24V（Electromagnetic） |
|
| |
| Automatic outside brushe |
|
Material：304 Stainless steel |
|
Overall dimension：1000*1000*1400 |
|
Motor power：0.75KW TAIZHOU of ZHEJIANG |
|
Water pump:0.37 KW NANFANG brand |
|
brush：united banister brush |
|
| |
| Automatic inside brush |
|
Material：304Stainless steel |
|
Overall dimension：1200*650*2000 |
|
Brush head：3 |
|
brushing time：batch- linear style |
|
Production capacity：120-200B/H |
|
Power：220W TAIZHOU of ZHEJIANG |
|
Pneumatic element：AIRTAC TAIWAN |
|
Soda solution rinsing |
|
Electromagnetic：1/2 AIRTAC |
|
PLC：Mitsubishi JAPAN |
|
Frame structure：38*38*1.2mm Stainless steel |
|
Board ：1.0mm thickness |
|
| |
| Automatic elevation barrel machine |
|
Overall dimension：5000×600×700 |
|
Pneumatic element： AIRTEC TAIWAN |
|
In order to reduce the friction on the battle bottom, adopting the engineering plastic for conveying the empty barrel |
|
Gearing： HA’ ER BIN Bearing factory 206 2set |
|
Frame structure： 38×38 304stainless steel can adjust the height |
|
Motor：Non-grade speed regulation TAIZHOU of ZHEJIANG |
|
| |
| Rinsing/ Filling / Pressure lid |
|
Production capacity：120-200B/H |
|
Material：304 Stainless steel |
|
Frame structure：75*45*1.2mm Stainless steel |
|
Electrical consumption：4KW |
|
Pneumatic element ：AIRTACT |
|
PLC：Mitsubishi Japan |
|
Pump： 6sets NANFANG Hangzhou |
|
Handling lid motor： 140W ZHEJIANG |
|
Electrical element：DELIXI |
|
Overall dimension：4200*1000*1600mm |
|
working position distribute： |
| |
|
The first step：soda inner rinsing（9KW Electrical heating） |
|
The second and third step：disinfection inner and outer rinsing |
|
The fourth and fifth step：recycle water inner rinsing
|
|
The sixth and seventh step：sterile water inner rinsing
|
|
The eighth step：drain water |
|
|
Filling head：3piece |
|
pressure lid part chain pressure lid Motor power:180W |
|
| |
| Shrinking film |
|
100degree steam Automatic controlling temperature |
|
Overall dimension:1000X500X950 |
|
Power:3KW |
|
Automatic steam generator 1 set |
|
| |
| Output barrel conveying |
|
conveying direction depends on user chose |
|
Material：304 Stainless steel |
|
Basic length：5M |
|
Speed regulation motor：0.75KW TAIZHOU of ZHEJIANG |
|
Conveying belt：191.5*38.3 engineering plastic |
|
Overall dimension：5000*500*150mm |
|
| |
| Lamp inspection |
|
Inspection capacity：200B/H |
|
Power：90W |
|
Overall dimension：800*300*1200mm |
|
Material：304Stainless steel |
|
inspection lamp： PHILIPS |
|
| |
| 400 BPH Line – Complete Automatic from A to Z |
| |
| Working flow sheet: |
5 gallon bottling production line function include:
Auto removing caps → Bottle outer washing → Auto bottle install → Auto washing filling capping
(main machine) → Sealing → finished product (Auto working fully all position) |
| |
| 5gallon Drinking water production line (400BPH) |
| |
| Name |
Photo |
Details: |
Complete line |
 |
Auto remove caps, bottle outer washing, auto install bottles to the main machine (washing bottle, filling water, capping), auto shrink the label film |
| Detail of Combination |
Auto cap remover |
 |
1) Make of stainless steel-304
2) Telepathy bottles and auto remove caps
3) Pneumatic working |
Auto bottle outer washing machine |
 |
1) Make of stainless steel-304
2) Telepathy bottles
3) Washing bottles with brusher |
Auto bottle install machine |
 |
1) Make of stainless steel-304
2) Telepathy bottles
3) Pneumatic put bottles to the Washing Filling Capping Machine |
Washing failing capping machine
(main machine) |
 |
1) Washing bottle with chemistry and pure water, filling water speediness and capping all right
2) High efficiency and working stabilization
3) Auto working by PLC-control |
Shrinking machine |
 |
1) Make of stainless steel-304
2) Steam shrink labels |
|
| |
| Detail explain of the machine |
|
Machine make of stainless steel. The stainless steel used is S.S304 |
|
3-in 1 function: washing bottle, filling water and capping |
|
Whole machine working controlled by PLC (programmable logical controller) of Panasonic brand, with CE marks, the machine works steadily, easily handle and maintained.. PLC controlling all the steps working automatic as a brain of the machine. |
|
Ground line could bear 1300V |
|
All the electric wire connected as standard of CE, no wire bare, all the wire in wire groove protected. All the connection of wire are protected well by soft plastic pipe. |
|
The control panel is hermetical, no dust or water will goes into it, no leak at any connection. |
|
Control panel is on up side of out-let, electric wire and air line installed separately. |
|
All the board could be taken down, easy and convenient for maintains. |
|
While there is no water or lack water in the pure water tank, the filling machine stops automatically. |
|
All the connection of weld is plat with nice looking and no burr remained. Avoid any hurting while operation |
|
All the electric parts connect to public point in control panel with main power wire then connect with the ground. Make sure all the part of the machine are well protected while the power is not that steady, protect your workers well. |
|
Cylinders working by pneumatic, save energy and working steadily. |
| Cylinders is protected by stainless box |
|
| |
|
| Name |
XG-100A (400BPH) |
Brand |
| Cylinder |
63*450*1pcs |
Taiwan AirTAE
brand with CE marks |
| 40*350*2pcs |
| 40*400 |
| 50*50*2pcs |
| F.R.L. Combination |
BFC-3000*1 item |
| (Water and oil separator) |
| Electric appliances |
1 series |
Taiwan brand
with CE marks |
| Programmable Logical |
FP1-14-AC*1 item |
Panasonic brand
made in china with CE |
| Controller(PLC) |
Expansion FP1-E8*1pcs |
| Temperature display |
OMRON 1pc |
|
| Stainless steel pump |
BLZ 370W*6pcs
BLZ750W*3pcs |
Made in China,
Guangdong with CE marks |
| Cap ordering |
90YYJ60-3 1：30*2 pcs |
Made in China Zhejiang with CE marks |
| Electric monitor |
|
Stainless steel
Electromagnetic Valve |
ZCS-15L*2 pcs
ZCS-25L*3pcs |
Made in China,
Chongqing CE |
| Stainless Armor plate |
304 |
|
| Pipe |
304 |
|
| Power |
6500W
(including heat generating pipe 2KW) |
|
| |
2 lines 7 sections |
|
| Working sections |
1, 2, 3 washing position with detergent water inner flushing
4 position for dry bottles
5 & 6 washing positions with recycled pure water inner flushing
7 position with pure water inner flushing |
|
|
| |
| GIECL Automatic Turnkey Bottled Water Project for Mineral Water Industry |
| 5 Gallon Automatic High Speed Line |
 |
| Rotary 1000 jar per hour Fully Automatic 5 Gallon Brushing, Washing in and Out with Filling and Capping with Auto Loading and Discharge with Neck Shrinking labeling |
| |
| 5 Gallon High Sped Machine |
 |
| |
| |
| GIECL Take the Complete Turnkey Projects as per Customer's Requirements. GIECL has Affiliation with related Machineries manufacturers and have executed such Projects Nationally and Internationally |
| |
|
GIECL Take the Complete Project right from Designing, Engineering, Manufacturing, Erection and Commissioning at site with Trail Production |
|
GIECL Provides all Technical supports for Buildings and Electrification for Projects |
|
GIECL supporting for Licenses and Documentation |
|
GIECL supply all Equipments as required and are responsible for its Installation. |
|
GIECL supply its all Components as per International standard and Multinational Manufacturer norm |
|
GIECL supply all Machineries with standard Spares and Consumables with Supply and post Monitoring of its uses |
|
GIECL Turnkey Project's Key Factor is its Low Production Cost as it is working by optimizing Efficiency |
|
GIECL strength is its Specialization in Training at Site which gives Trouble free Operation |
|
GIECL Furnish the Complete Installation and Commissioning at site in Record Period |
|
GIECL Technical Supports after Installation of Project gives customer strength and our Customer care department constantly monitoring the Operation by its Communication and documentation |
|
GIECL also Provide 24 hours online phone and Physical Service Back up to its Customer having contract with UPS and DHL services for immediate supply |
|
GIECL also making Flying Visit to its existing customer for observation and maintenance & operation at site |
|
GIECL believes in Strong and Long terms Customer relationship |
| |
|
|
| |
| |
